Steel prop / shoring post

Short Description:


  • Min.Order Quantity: One container
  • Production time: usually 25 days
  • Port: Xingang Tianjin Port in China
  • Payment Terms: L/C,D/A,D/P,T/T
  • Material: Q235 Steel Pipe
  • Surface Treatment: Electro-galvanized, Pre-galvanized, Hot dipped galvanized, Painted, Powder-coated
  • Standard: EN1065:1998
  • Product Detail

    Product Tags

    scaffolding

    Steel prop / shoring post

    Material: Q235 Steel Pipe   Standard: EN1065:1998

    Finish: Electro-galvanized, Pre-galvanized, Hot dipped galvanized, Painted, Powder-coated

    Light duty prop - Spanish Prop  ( Wall Thickness : 1.4-2.5 mm)

    Min Height Max Height Inner Tube Outer Tube
    1.6 m 3 m 40 mm 48 mm
    0.8 m 1.4 m 40 mm 48 mm
    1.8 m 3.2 m 40 mm 48 mm
    2 m 3.6 m 40 mm 48 mm
    2.2 m 4 m 40 mm 48 mm
    Light duty prop - Spanish Prop

    Light duty prop - Italian Prop  ( Wall Thickness : 1.4-2.75 mm)

    Min Height Max Height Inner Tube Outer Tube
    1.6 m 2.9 m 48 mm 56 mm
    1.8 m 3.2 m 48 mm 56 mm
    2 m 3.6 m 48 mm 56 mm
    2.2 m 4 m 48 mm 56 mm
    Light duty prop - Italian Prop

    Heavy duty prop- Middle East prop ( Wall Thickness : 1.4- 4 mm)

    Min Height Max Height Inner Tube Outer Tube
    1.7 m 3 m 48 mm 60 mm
    1.8 m 3.2 m 48 mm 60 mm
    2 m 3.6 m 48 mm 60 mm
    2.2 m 4 m 48 mm 60 mm
    3 m 5 m 48 mm 60 mm
    Heavy duty prop- Middle East prop

    Push - Pull Prop / Triangle prop ( Wall Thickness : 1.4- 4 mm)

    Min Height Max Height Inner Tube Outer Tube
    1.6 m 2.9 m 48 mm 60 mm
    1.8 m 3.2 m 48 mm 60 mm
    2 m 3.6 m 48 mm 60 mm
    2.2 m 4.1 m 48 mm 60 mm
    3 m 5 m 48 mm 60 mm
    Triangle prop

    Steel prop accessories

    Tripod

    Tripod

    Sleeve

    Sleeve

    Fork Head

    Fork Head

    Square and flower Plate

    Square and Flower Plate

    Prop Nut

    Prop Nut

    Prop Nut

    Prop Nut

    Prop Nut

    Prop Nut

    Prop Pin

    Prop Pin

    Prop Pin

    Prop Pin

    Prop Pin

    Prop Pin

    Packing and Loading:

    PROPS PACKAGE
    PROPS LOADING
